The FZ-5 is a modern pedal built for the modern guitarist, but the sounds you can get from the FZ-5 are pure retro. Looking back at the glorious rock sounds of the ’60s and ’70s, the FZ-5 recreates its vintage fuzz through BOSS state-of-the-art COSM technology. Recall the fuzz-filled flavors of classic pedals, such as the Maestro FZ-1A, Fuzz Face and Octavia pedals, and kick ’em into overdrive with the FZ-5’s Boost knob. BOSS’ proprietary COSM technology allows guitar players to recreate classic fuzz BOOST control for more aggressive tone. The FZ-5 is the perfect weapon for players wanting to beef up their rigs with classic retro fuzz artillery.

• Vintage sounds inspired by famous fuzz pedals of the ’60s and ’70s
• Uses advanced COSM technology to recreate classic fuzz
• BOOST control for more aggressive tone
• Road-tough BOSS metal construction
• BOSS five-year warranty

Nominal Input Level

-20 dBu

Input Impedance

1 M ohm

Nominal Output Level

-20 dBu

Output Impedance

1 k ohm

Recommended Load Impedance

10 k ohms or greater

Bypass

Buffered bypass

Controls

FUZZ knob
MODE knob
LEVEL knob
Pedal switch

Indicator

CHECK indicator (Serves also as battery check indicator)

Connectors

INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
DC IN jack

Power Supply

Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)

Current Draw

60 mA

Expected battery life under continuous use

Alkaline: Approx. 4 hours
*These figures will vary depending on the actual conditions of use.

Accessories

Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Alkaline battery (9 V, 6LR61)

Options (sold separately)

AC adaptor: PSA series

Size and Weight

Width

73 mm
2-7/8 inches

Depth

129 mm
5-1/8 inches

Height

59 mm
2-3/8 inches

Weight (including battery)

405 g
15 oz

* 0 dBu = 0.775 Vrms
*The specifications are subject to change without notice.
